Produktinfo
Specifications:
| Stator Diameter | 22.0 mm (0.87 in) |
| Stator Thickness | 21.0 mm (0.83 in) |
| No. of Stator Arms | 9 |
| Magnet Poles | 6 |
| Motor Wind | 8 Turn Delta |
| Motor Wire | 16-Strand 0.21mm |
| Motor Kv | 3595 RPM / Volt |
| No-Load Current (Io) | 2.31 Amps @ 10 volts |
| Motor Resistance (Rm) | 0.024 Ohms |
| Max Continuous Current | 45 Amps |
| Max Continuous Power | 475 Watts |
| Weight | 81 Grams (2.86 oz) |
| Outside Diameter | 27.9 mm (1.098 in) |
| Shaft Diameter | 3.17 mm (0.125 in) |
| Body Length | 38.3 mm (1.508 in) |
| Overall Shaft Length | 58.7 mm (2.311 in) |
| Max Lipo Cell | 3s |
| Motor Timing | 5deg |
| Drive Frequency | 8kHz |
